Description EVID 3.2 Dual 3.5″ 2‑Way Surface-Mount Loudspeaker Ultra-compact full range Ideal for restaurants, bars, patios, and retail Vented LF enclosure 0.75-inch titanium diaphragm HF driver with neodymium magnetic structure Full-bandwidth overload protection (LF and HF) Elliptical weather-resistant ABS enclosure Paintable black or white finish Magnetically shielded for video applications Strong-Arm Mount™ for easy, flexible aiming “T” version for 70 or 100 V distributed systems Specifications Frequency Range (-10 dB) 85 – 20000kHz Weight Net 52.91oz (1500g) Depth 165mm (6.5″) Width 127mm (5″) Height 234mm (9.21″) Available Color Black or white Chassis Size 88.9mm (3.5″) Coverage (Nominal -6 dB) H 140° Coverage (Nominal -6 dB) V 100° HF Transducer 0.75-inch Input Connections Spring Terminal LF Transducer Two 3.5-inch Max. SPL/1m (calc) 112dB Minimum Impedance 6Ω Nominal Impedance (Passive) 8Ω Power Rating 300W Sensitivity 1 W/1 m 87dB Speaker Type Full-Range, Mid-High, Two-Way System Power Handling (Continuous/Program/Peak) 75//300Watts Transformer Taps (Transformer Version Only) 70 V: 5 W, 100 V:10 W Weatherized Yes Download Datasheet
